Name: S5731-H48T4XC
Brand: MY SHOP
Availability: InStock
Rating: 5 (1 reviews)

Description

CloudEngine S5731-H series switches are brand-new enhanced gigabit access switches that provide all-GE electrical downlink ports, fixed 10GE uplink ports, and one extended slot.
CloudEngine S5731-H delivers gigabit connectivity at the aggregation or access layer in large and midsize campuses, at the core layer in branches and small campuses, and at the access layer in data centers. Integrating native WLAN AC capabilities to support up to 1024 WLAN APs, CloudEngine S5731-H enables you to converge your wired and wireless networks for simplified operations. It also offers free mobility to deliver consistent user experience and VXLAN-based virtualization to create a multi-purpose network. With built-in security probes, CloudEngine S5731-H supports abnormal traffic detection, Encrypted Communications Analytics (ECA), and network-wide threat deception.

Specification of S5731-H48T4XC
Fixed port	48 x 10/100/1000Base-T ports, 4 x 10GE SFP+ ports
Dimensions (H x W x D)	43.6 mm x 442 mm x 420 mm
Chassis height	1 U
Chassis weight (including packaging)	8.55 kg
Extended slot	One extended slot, support 2 x 40GE, 8 x 10GE Base-T and 8 x 10GE SFP+ cards
Power supply type	600W AC(pluggable) 150W AC(pluggable) 180W DC(pluggable) 1000W DC(pluggable)
Rated voltage range	AC input (600W AC ): 100V AC to 240V AC, 50/60Hz AC input (150W AC ): 100V AC to 240V AC, 50/60Hz DC input(180/1000W DC): -48V DC to -60 V
Maximum voltage range	AC input (150W AC ): 90V AC to 264V AC, 47Hz to 63Hz AC input (600W AC ): 90V AC to 290V AC, 45Hz to 65Hz High-voltage DC input (600 W AC): 190V DC to 290V DC (meeting 240V high-voltage DC certification) DC input (180/1000W DC): -38.4 V DC to -72V DC
Maximum power consumption	124W/130W
Operating temperature	0-1800 m altitude: -5°C to 45°C/40°C 1800-5000m altitude: The operating temperature reduces by 1ºC every time the altitude increases by 220 m.
Storage temperature	-40°C to +70°C
Relative humidity	5% to 95% (non-condensing)
Surge protection specification (service port)	Common mode: ±6 kV
Surge protection specification (power port)	AC power port: ±6kV in differential mode, ±6 kV in common mode DC power port: ±2kV in differential mode, ±4 kV in common mode
Heat dissipation	Air cooling heat dissipation, intelligent speed adjustment, and pluggable fans -B model: Air flows in from the rear panel and exhausts from the front side
